Waterflooding recovers more oil worldwide than any other method, and most waterfloods underperform their potential. The reasons are consistent: injected water follows the highest permeability path, arrives early at some producers and never reaches others, injection is unbalanced between patterns, voidage is not replaced where it matters, and by the time the water cut has risen nobody can establish which injector is responsible. These are surveillance and analysis failures rather than reservoir failures, and they are correctable.

A waterflood is a displacement process operating in a rock body nobody can see. Water is injected at one location and oil is produced at another, and everything of importance happens in between. The engineer has injection rates and pressures, production rates and water cuts, some pressure measurements, and a geological model of uncertain accuracy. From those observations the flood has to be diagnosed and steered.

The physics sets the limits. Displacement efficiency at the pore scale is governed by relative permeability and residual saturation and cannot be improved much by operational means. Sweep efficiency, by contrast, is largely under operational control and is where most of the recoverable oil is won or lost. Water preferentially enters high permeability layers, fingers ahead in unfavourable mobility ratio conditions, segregates under gravity in thick sands, and short-circuits along fractures or through unbalanced patterns. Recognising which of these is occurring, from production data rather than from assumption, is the central analytical task.

The diagnostic tools are well established and underused. A Hall plot reveals whether an injector is losing injectivity, taking water outside the intended zone, or has fractured. A water-oil ratio plot distinguishes normal displacement from channelling. Voidage replacement calculations show whether the flood is maintaining pressure or merely moving water. Rate correlation between injectors and producers identifies which wells are actually connected, frequently contradicting the pattern map. Applied consistently and early, these methods turn a waterflood from something that happens into something that is managed. This course builds them all.

By the end of this training, participants will be able to:

• Apply fractional flow and frontal advance theory to predict breakthrough time and recovery
• Evaluate mobility ratio and its effect on displacement stability and sweep
• Calculate areal, vertical and displacement sweep efficiency and identify which is limiting recovery
• Analyse stratified reservoir performance using layer-based and permeability variation methods
• Calculate voidage replacement ratio and assess pressure maintenance across the flood
• Construct and interpret Hall plots and track injectivity index for injection well surveillance
• Interpret water-oil ratio diagnostic plots to distinguish displacement from channelling and coning
• Determine injector-producer connectivity from rate response and allocate injection support
• Diagnose conformance problems and evaluate remediation and pattern rebalancing options
• Evaluate infill drilling and pattern modification opportunities from surveillance evidence

Organisations sending participants to this training will:

• Increase recovery from existing waterfloods without additional injection capacity
• Identify and correct channelling, unbalanced patterns and ineffective injection
• Reduce water handling and lifting cost by cutting recycled water volumes
• Improve targeting of conformance treatments and infill drilling
• Establish consistent waterflood surveillance across the asset

Participants will:

• Diagnose waterflood behaviour from production and injection data
• Distinguish between the sweep mechanisms limiting recovery in a given flood
• Build the standard waterflood surveillance calculations independently
• Recommend and justify pattern changes, conformance work and infill locations
• Track flood performance systematically rather than reactively
• Take technical ownership of waterflood management for an asset

• Reservoir engineers responsible for waterflood management
• Production engineers dealing with high water cut and injection wells
• Petroleum engineers involved in secondary recovery projects
• Surveillance and production analysts in subsurface teams
• Field development engineers evaluating infill and pattern changes
• Simulation engineers seeking analytical validation of flood models
• Technical supervisors responsible for secondary recovery performance

Upon successful completion of this training course, delegates will be awarded an official Certificate of Completion issued by the Petroleum Engineers Association (PEA), an ISO 9001:2015 certified training organization. The certificate carries 10 Credits and formally records the total learning hours completed.

Each certificate is signed by the Course Facilitator and the CEO of the Petroleum Engineers Association, and serves as verifiable proof of professional training that delegates can present to employers and professional bodies worldwide.
