An Interactive 5-Day Training Course
Coiled Tubing Operations & Design
Design, Limits and Field Execution
Secure your spot now!
Duration
5 Days
Price
$ 3,000
Starting From
18 Oct 2027
Coiled Tubing Operations & Design
Have Questions ?
Coiled Tubing Operations & Design - PE-CTO-PEA27
| Code | Date | Time | Duration | Location | Currency | Early Bird Fee Per Person |
|---|---|---|---|---|---|---|
| PE-CTO-PEA27 | 18 - 22 Oct 2027 | 10 AM CST | 4 Hours Per Day |
Online |
USD |
3000 |
Need this for a group? We deliver the same course in-house — face-to-face at your location or online — tailored to your assets and team level. Contact info@peassociations.com.
Boost your team's skills and your budget! Enjoy group discounts for collaborative learning. Send an inquiry to info@peassociations.com.
Coiled Tubing Operations & Design
Description
Coiled tubing allows work to be done in a live well with continuous pipe that can circulate fluid, carry tools and be run and pulled under pressure. It is used for clean-outs, milling, stimulation, nitrogen kick-offs, logging in horizontal wells, fishing and many other tasks, and it sits between wireline and a workover rig in both capability and cost.
This course covers the engineering and the operations. It starts with string properties, manufacture, fatigue life and derating, then covers force analysis, lock-up and buckling in deviated and horizontal wells, and hydraulics including friction pressure, nitrogen and foam. It then covers surface equipment, pressure control stacks and bottomhole assemblies, before moving to the main applications: clean-outs, milling, acidising, nitrogen lifting, logging, fishing and zonal isolation. The course closes with job design, execution, quality control and emergency and contingency procedures.
Coiled tubing is a slender pipe pushed into a well against friction. Whether it reaches the target depends on the balance between weight, friction and buckling. In a horizontal well the pipe eventually locks up, and no more force at surface moves it deeper. Predicting that limit before the job is the central design calculation, and it drives decisions on tubing size, lubricants, tractors and the use of downhole thrusters.
Fatigue is the second design issue. Every trip over the reel and gooseneck bends and straightens the pipe, and pressure inside it increases the damage. Fatigue life is tracked cycle by cycle, and a string that is not tracked correctly can fail downhole, which turns a routine job into a fishing operation with pipe in a live well.
Hydraulics limits what can be pumped. The small bore of coiled tubing produces high friction pressure, which restricts rate and sets limits on the fluids that can be used, particularly for acid placement and clean-outs where annular velocity has to carry solids to surface. Get any of these three wrong and the job either fails to reach depth, fails to clean out or damages the string. This course covers all three in the detail needed to design and supervise jobs.
By the end of this training, participants will be able to:
- Describe coiled tubing string manufacture, properties and specifications.
- Calculate and track fatigue life and apply derating for pressure and ovality.
- Perform force and buckling analysis and predict lock-up depth.
- Evaluate methods for extending reach in horizontal wells.
- Calculate circulating pressures and hydraulics, including nitrogen and foam.
- Specify surface equipment and pressure control stacks.
- Select bottomhole assemblies for the intended task.
- Design clean-out, milling, stimulation, nitrogen lift and logging jobs.
- Plan job execution, quality control and monitoring.
- Apply emergency and contingency procedures, including stuck pipe and pipe failure.
Organisations sending participants to this training will:
- Improve coiled tubing job success rates and reach in horizontal wells.
- Extend string life and avoid in-hole pipe failures.
- Improve job design quality and reduce non-productive time.
- Strengthen pressure control and emergency preparedness.
- Reduce intervention cost by using coiled tubing where a rig is not needed.
Participants will:
- Understand coiled tubing string mechanics, fatigue and hydraulics.
- Be able to design a coiled tubing job and predict its reach.
- Understand pressure control equipment and its operation.
- Be able to select bottomhole assemblies for each application.
- Be able to supervise execution and respond to problems.
- Well intervention engineers
- Production engineers
- Coiled tubing service engineers and supervisors
- Completion engineers
- Well services operations staff
- Field supervisors on intervention operations
Module 1: Coiled Tubing Systems
- System components and layout
- Capabilities compared with wireline and workover rigs
- Typical applications
- Onshore and offshore operations
Module 2: String Properties and Fatigue
- Manufacture, materials and specifications
- Tapered strings
- Fatigue mechanisms and cycle counting
- Effect of internal pressure and ovality
- String management and retirement criteria
Module 3: Force Analysis and Reach
- Weight, friction and buckling
- Helical buckling and lock-up
- Reach prediction in deviated and horizontal wells
- Friction reducers, rollers, tractors and thrusters
- Weight indicator interpretation
Module 4: Hydraulics
- Friction pressure in coiled tubing
- Annular velocity and solids transport
- Nitrogen and foam hydraulics
- Circulating pressure limits
- Fluid selection
Module 5: Surface and Pressure Control Equipment
- Reel, injector head and gooseneck
- Power pack and control cabin
- Stripper, blowout preventers and riser
- Well control barriers during coiled tubing operations
- Equipment testing and certification
Module 6: Bottomhole Assemblies
- Connectors, check valves and disconnects
- Nozzles and jetting tools
- Motors and mills
- Logging and perforating conveyance
- Fishing and mechanical tools
Module 7: Applications
- Fill and sand clean-outs
- Scale milling and removal
- Acid and chemical placement
- Nitrogen kick-off and unloading
- Logging in horizontal wells
- Cement and zonal isolation work
- Fishing with coiled tubing
Module 8: Job Design and Execution
- Objectives, success criteria and job programme
- Pre-job calculations and checks
- Wellsite quality control
- Real-time monitoring of weight and pressure
- Job reporting
Module 9: Emergencies and Contingencies
- Stuck coiled tubing
- Pipe failure and parted string
- Loss of well control
- Emergency disconnect procedures
- Fishing and recovery of coiled tubing
Upon successful completion of this training course, delegates will be awarded an official Certificate of Completion issued by the Petroleum Engineers Association (PEA), an ISO 9001:2015 certified training organization. The certificate carries 10 Credits and formally records the total learning hours completed.
Each certificate is signed by the Course Facilitator and the CEO of the Petroleum Engineers Association, and serves as verifiable proof of professional training that delegates can present to employers and professional bodies worldwide.
